    RPMT 1204MO-MM Carbide CNC Milling Inserts Worldia Cutting Tools

    Ask Lasest Price
    Brand Name : Worldia
    Model Number : RPMT 1204MO-MM
    Payment Terms : L/C, D/A, D/P, T/T, Western Union
    Delivery Time : 15days
    • Product Details
    • Company Profile

    RPMT 1204MO-MM Carbide CNC Milling Inserts Worldia Cutting Tools

    RPMT 1204MO-MM PVD Coating carbide insert for CNC milling processing


    INTRODUCTION


    Carbide Inserts, Cermet Inserts, and Carbide Bars are the main products.

    Our products are widely used in the mold industry, instruments and apparatus, automotive parts,

    engineering machinery, energy equipment, and other industry products processing and manufacturing.


    PVD Coating carbide milling brand


    MaterialISOFeature
    CT5020M15-M30Super micron substrate with better wear resistance
    Suit for steel, stainless steel, and high-temperature alloy under the stable cutting
    condition that on common to semi-finish
    Perghardened steel on semi-finish
    P15-P30
    S15-S30
    CT5025M15-M35The first choice of universal machining
    Steel, stainless steel, and high-temperature alloy on common machining under
    the stable condition
    P15-P35
    S15-S35
    CT5035M25-M45High toughness substrate, suit for interrupted cutting at the low condition
    Stainless steel, steel on the interrupted cutting
    P25-P45
    CT020KK10-K30Specialized for cast iron on milling, grey cast iron, and ductile cast iron on universal machining
    CT3010S05-S25Super micron substrate, steel, and hardened steel at a high-speed cutting
    H05-H25

    SPECIFICATION


    TypeCutting Data
    F(mm/rev)Ap(mm)
    RPMT08T2MO-MM0.20-0.550.15-3.50
    10T3MO-MM0.20-0.700.20-5.00
    1204MO-MM0.30-0.850.20-6.00
    1606MO-MM0.30-1.100.30-8.00

    Cutting case


    BrandWorldiaOther brands
    TypeCMGDN 400-030 C CT5025DGN 4003 ****
    Workpiece41304130
    Machining wayGroovingGrooving
    Cutting speedVc=150m/minVc=150m/min
    Feedfn=0.12mm/rfn=0.12mm/r
    Deepap=8mmap=8mm
    CoolingOut cooling(oil)Out cooling(oil)
    Life60min60min
