    CCGT060204 Square Polycrystalline Diamond Inserts CCGT Carbide Inserts

    Ask Lasest Price
    Brand Name : ManaNova
    Model Number : CCGT060204
    Certification : ISO9001,14001.18001, RoHS
    Price : $20-40/ Piece
    Payment Terms : L/C, T/T, D/A, D/P
    Supply Ability : In stock
    Delivery Time : 3-4days
    • Product Details
    • Company Profile

    CCGT060204 Square Polycrystalline Diamond Inserts CCGT Carbide Inserts

    CCGT060204 Standard Carbide Turning PCD Cutting Insert for non-ferrous materials


    Material:

    Tools with Poly-Crystalline Diamond (PCD) cutting materials can reduce your tooling cost significantly,

    PCD tools are ideal for use with non-ferrous metal.

    PCD Turning Inserts can be used in many fields including the car industry, energy equipment, and the wood

    and stone industry.


    Specification:


    AngleDimensionsGrade
    ANSI CodeISO CodeTipsIC
    mm
    S
    mm
    R
    mm
    Φd
    mm
    LE
    mm
    MND
    10
    CCGT 21.50.5CCGT 0602021N6.352.380.22.82.5
    CCGT 21.51CCGT 0602041N6.352.380.42.82.5
    CCGT 32.50.5CCGT 09T3021N9.5253.970.24.42.5
    CCGT 32.51CCGT 09T3041N9.5253.970.44.42.5
    CCGT 32.52CCGT 09T3081N9.5253.970.84.42.5

    For another ISO Code, please contact us!


    Application:


    MND10Applied to the cutting of non-ferrous materials such as aluminum alloys, etc.

    PCD tools are limited to non-ferrous materials, such as high-silicon aluminum, metal matrix composites (MMC), and carbon fiber reinforced plastics (CFRP).
    PCD with flood coolant can also be used in titanium super-finishing applications.
    ·Aluminum and aluminum alloys
    ·Copper, brass, and bronze alloys
    ·Zinc and magnesium alloys
    ·Carbon Fiber
    ·Epoxy resins
    ·Plastics
    ·Fiberglass composites
    ·Graphite composites


    Description:

    MANANOVA is the sub-brand of WORLDIA, positioned as a high-end standard series,

    mainly promoting PCD / PCBN standard inserts.


    Main products:

    PCD insert: Providing stable, universal, high efficient cutting effect.
    PCD Turning Inserts can be used in many fields including the car industry, energy equipment, and the wood and stone

    industry. It can be used to cut and process different materials such as nonferrous metal, tungsten carbide, ceramic,
    nonmetal, and composite material.

    PCBN insert: 7material/ 1 type, universal for hardened steel, cast iron, ductile iron, and powder metallurgy.

    Advantages:
    · Universal
    · Easy choice
    · Fast delivery


    Service:
    · Online store service
    · Local distributor support
    · Technical support


    Feed rate recommendation
    Nose radius(mm)Ra um
    0.20.40.81.63.26.4
    Feed Rate f (mm/rev)≤
    0.20.0280.0400.0570.0800.1130.160
    0.40.0400.0570.0800.1130.1600.226
    0.80.0570.0800.1130.1600.2260.320
    1.20.0690.0980.1390.1960.2770.392
    1.60.0800.1130.1600.2260.3200.453
    2.40.0980.1390.1960.2770.3920.554
