    Thermal Shock Resistance PCBN Cutting Inserts Gray Cast Iron DCGW Insert

    Ask Lasest Price
    Brand Name : ManaNova
    Model Number : DCGW 070204
    Certification : ISO9001,14001.18001, RoHS
    Price : $20-40/ Piece
    Payment Terms : L/C, T/T, D/A, D/P
    Supply Ability : In stock
    Delivery Time : 3-4days
    • Product Details
    • Company Profile

    Thermal Shock Resistance PCBN Cutting Inserts Gray Cast Iron DCGW Insert


    DCGW070204 Coated PCBN Carbide Turning Insert CBN Cutting Insert for hardened steel


    Description:

    MANANOVA is the sub-brand of WORLDIA, positioned as a high-end standard series,

    mainly promoting PCD / PCBN standard inserts.


    PCBN insert is suitable for machining hardened steel, gray cast iron, ductile iron, and powder metallurgy.

    PCD insert is suitable for rough and finish machining of aluminum alloy and other non-metal materials.


    Main products:


    PCD Turning Inserts can be used in many fields including the car industry, energy equipment,

    and the wood and stone industry. It can be used to cut and process different materials such as

    nonferrous metal, tungsten carbide, ceramic, nonmetal, and composite material.


    Polycrystalline cubic boron nitride(CBN) is a material with an excellent hot hardness that can be used at very high

    cutting speeds. It also exhibits good toughness and thermal shock resistance.CBN tools are ideal for the use with

    hardened steel, cast irons, and sintered irons as well as powder metallurgy components.


    Advantages:

    MANANOVA takes “Easy choice and Fast delivery” as the feature,

    which intends to provide fast and efficient service for domestic and foreign customers to meet

    their demand for standardized and universalized tools.



    Service:
    · Online store service
    · Local distributor support
    · Technical support


    Application:

    Worldia ManaNova series covers 7 high-quality CBN grades for the processing of hardened steel, cast iron,

    and powder metallurgy, the available grades are MHN10C, MHN20C, MHN30C, MKN10, MKN20, MSN10, and MSN20.


    MHN10CApplied to the continuous cutting of hardened steel
    MHN20CApplied to medium interrupted cutting of hardened steel
    MHN30CApplied to the heavy interrupted cutting of hardened steel
    MKN10Applied to the cutting of gray cast iron
    MKN20Applied to the cutting of ductile iron
    MSN10Applied to the cutting of powder metallurgy
    MSN20Applied to the cutting of powder metallurgy

    Specification:


    MaterialISO HISO KISO S
    PCBN GradeMHN10CMHN20CMNH30CMKN10MKN20MSN10MSN20
    SmoothModerateToughnessCast IronDuctile IronPowder MetallurgyPowder Metallurgy
    Vc180(150~250)
    m/min
    100(50~150)
    m/min
    80(30~120)
    m/min
    600(300~800)
    m/min
    300(150~450)
    m/min
    300(200~500)
    m/min
    500(300~800)
    m/min
    fn0.1(0.03~0.2)
    mm/r
    0.1(0.03~0.2)
    mm/r
    0.1(0.03~0.2)
    mm/r
    0.1(0.03~0.3)
    mm/r
    0.1(0.03~0.3)
    mm/r
    0.1(0.03~0.3)
    mm/r
    0.1(0.03~0.3)
    mm/r
    %45~5560~7085~9585~9560~7060~7085~95
    Grain size1~2 um1~2 um2~3um2~3 um1~2 um1~2 um2~3 um
    BondTiCTiNCo/WCo/WTiCNTiCNCo/W

    DCGWShapeDimensions
    ANSI CodeISO CodeTipsIC
    mm
    S
    mm
    R
    mm
    Φd
    mm
    LE
    mm
    All
    Stocked
    DCGW 21.51DCGW 0702042N6.352.380.42.82.2
    DCGW 21.52DCGW 0702082N6.352.380.82.82.2
    DCGW 32.50.5DCGW 11T3022N9.5253.970.24.42.2
    DCGW 32.51DCGW 11T3042N9.5253.970.44.42.2
    DCGW 32.52DCGW 11T3082N9.5253.970.84.42.2
