    Worldia ISO standard In stock and fast delivery Milling Tools PCD inserts for milling non-ferrous finishing materials

    Ask Lasest Price
    Brand Name : Worldia
    Model Number : BEHW PCD tipped Milling Inserts
    Delivery Time : 5-15
    Supply Ability : 20000
    MOQ : 10 PCS
    • Product Details
    • Company Profile

    Worldia ISO standard In stock and fast delivery Milling Tools PCD inserts for milling non-ferrous finishing materials

    Design Feature:

    Applications:

    • BEHW PCD-tipped Milling Inserts for Light and Medium Applications
      PCD-tipped milling inserts with various angles, wipers and corner radii for face and shoulder milling applications with higher depth of cut and Si-content ≤10%.
      BEHW PCD-tipped Milling Inserts for Heavy-Duty Applications
      PCD-tipped milling inserts with various angles, wipers and corner radii for face and shoulder milling applications with higher depth of cut and Si-content ≥10%.
      BEHW PCBN-tipped Milling Inserts for Face and Shoulder Milling Applications
      PCBN-tipped milling inserts with various angles, wipers and corner radii for face and shoulder milling applications of cast iron and hardened materials with a higher depth of cut.
      SDHN Full-Face PCBN Milling Inserts for Finish Face Milling Applications
      PCBN full-face milling inserts with various angles and wipers for finish face milling of cast iron and hardened materials.

    Technical Parameters:

    Product Name:BEHW PCD Tipped Milling Inserts
    Machine Type:Face + Shoulder Milling
    Cutting Material:PCD
    Cutting Edges:6
    Standard Cutter Diameter (mm):25 - 40 Mm Or Above 40 Mm
    Max. DOC/ Ap (mm):4
    max RPM:40000
    Customized support:OEM, ODM, OBM
    Place of Origin:Beijing
    MOQ:10 PCS

    Specification:

    BEHW PCD-tipped Milling Inserts for Light and Medium Applications

    BEHW PCD-tipped Milling Inserts for Heavy Duty Applications


    PCD Grades and Application Recommendations
    :

    Workpiece
    Grade
    Grain size (μm)
    Characteristics
    Application
    Mater
    N
    ial
    PD10E
    10
    PD10E is the universal grade in the market. It’s the first choice for many applications where a
    good balance of toughness and wear resistance are required.
    This grade is commonly used for non-ferrous finishing applications. Other successful applications include machining of wood, MDF, low-medium content silicon aluminum alloys, carbide, hard rubber, graphite and so on.
    PD32E
    2~30
    PD32E has a unique combination of wear resistance, edge strength and edge quality. It contains a carefully selected mix of microns
    diamond (between 2 - 30 µm). The combination of these particle sizes and a specifically developed
    high-pressure sintering process produces a structure with extreme abrasion resistance and
    good thermal stability.
    Application areas include the machining of abrasive workpieces such as MMC, high silicon aluminum alloys as well as machining of carbide, hard rubber, graphite and other materials.

    FAQ:

    Q1: What is the brand name of the Face Milling Cutters product?

    A1: The brand name of the Face Milling Cutters product is Worldia.

    Q2: What is the model number of the product?

    A2: The model number of the product is BEHW PCD tipped Milling Inserts.

    Q3: Where is the product made?

    A3: The product is made in Beijing, China.

    Q4: What is the minimum order quantity for the product?

    A4: The minimum order quantity for the product is 1.

    Q5: What is the packaging details for the product?

    A5: The packaging details for the product is blue boxes.

    Q6: What is the delivery time for the product?

    A6: The delivery time for the product is 5-15 days.

    Q7: What is the supply ability for the product?

    A7: The supply ability for the product is 20000.
